QUESTION 23
Metallic shielding components such as tapes, wires, or braids shall be connected to a:

equipment grounding busbar.

low voltage ceramic insulator.

low voltage connector.

center tap of a transformer.

QUESTION 24
What is the process that aims to find potential defects in a product before it is released for delivery?

Inspection

Examination

Quality Control

Quality Assurance

QUESTION 25
According to ANSI/NETA/ATS, when performing a dielectric withstand test on each bus section, the test voltage shall be applied for how long?

One second

One minute

One hour

One day

QUESTION 26
What would the equipment pictured below be used for?

Precise measurement of shaft alignment

Precise measurement of machined equipment requiring close tolerances

Calibration of precision measuring equipment

Verification of proper spacing between motor and gearbox

QUESTION 27
What standard is used for the installation of signaling and communications conductors, equipment, and raceways?

IEC 20047

NEMA 250

NFPA 70

IEEE C37.20.2

QUESTION 28
What is the purpose of an equipment risk assessment in the source inspection process?

To identify the level of risk associated with failure of the supplier/vendor’s quality system

To identify the level of effort for source inspection activities during the manufacture/fabrication phase of a project at the supplier/vendor facility

To identify which shops will be able to bid on certain types of equipment i.e. to identify the shops that can supply equipment critical to project success

To determine the level of business insurance required in the event the supplier/vendor is unable to deliver the product on time while meeting contractual agreements

QUESTION 29
Which item is part of typical final inspection and shipping preparation for a liquid-immersed transformer?

Verification that all FAT issues are resolved

Reclassification of the project risk register

Reissue of procurement bid tabs

Elimination of all documentation requirements

QUESTION 30
In addition to maximum rated voltage, manufacturer’s name, trademark and AWG, which of the following markings is required for all conductors and cables?

Country of origin

NEC class

Batch or lot number

Wire type designator

QUESTION 31
According to NETA, for low voltage cables a visual inspection must verify that:

color codes comply with IEEE requirements.

the shield on power cables is properly grounded.

connections are in accordance with the single-line diagram.

all cables are connected to terminals via ring tongue lugs.

QUESTION 32
According to the referenced API standard in the guide, special purpose induction motors covered by API STD
541 are:

100 hp and larger

250 hp and larger

375 kW (500 hp) and larger

1000 kW and larger only

QUESTION 33
What is the purpose of a clamp meter?

To measure the magnetic field around a conductor

To test that the electrical equipment maximum temperature does not exceed the ignition temperature of gases in the environment

To externally measure the sum of the current flowing through the cable

To verify the process temperature and the equipment temperature have the same Class 1 rating

QUESTION 34
According to ANSI C57.12, each line terminal of a winding shall be tested to what maximum value?

Switching Impulse Insulation Level

Chopped Wave Insulation Level

Wye-Winding Insulation Level

Basic Lightning Impulse Insulation Level

QUESTION 35
What is an insulation resistance test?

A test that determines the adequacy of electrical insulation for the normally occurring over voltage transient

A test that determines the corrosive contaminants around the conductors, terminal spacing problems, and tolerance errors in cables

A spot overvoltage test which uses an applied DC voltage to measure ohms

A test that determines the voltage that electrical insulation can withstand during normal operation

QUESTION 36
The evaluation of a component for compliance with product specification and data sheet is known as:

standardization.

inspection.

validation.

documentation.

QUESTION 37
Which information should be included at a minimum in a source inspection report?

Inspector’s travel reimbursement total

Reference drawings/data used, including drawing numbers

Supplier profit margin

Internal purchaser budget code only

QUESTION 38
According to NFPA 70, is the use of Teflon tape on threaded connections for conduits allowed?

Only when installed in a Class I, Division 2 area

Yes, the use of Teflon on metal raceways, cable armor, and other metal enclosures prevents water from entering

No, metal raceways and other metal enclosures for conductors shall be metallically joined together into a continuous electrical conductor

Yes, the use of Teflon ensures an explosion proof vapor seal

QUESTION 39
Final inspection and shipping preparations of switchgear typically consists of verifying all of the following except:

all final manufacturing and drawing issues are closed.

correct engraving of unit and master nameplates.

visual inspection of packaging requirements.

all items on the manufacturer’s QC checkout are signed off.

QUESTION 40
What does the second letter of the four-letter cooling code on liquid-immersed transformers identify?

Internal cooling medium in contact with the windings

Circulation mechanism for internal cooling medium

External cooling medium

Circulation mechanism for external cooling medium

QUESTION 41
When might a resident source inspector be required at a shop during manufacture and fabrication?

When the risk assessment classifies the equipment item as highest risk

When the item is procured from a foreign source

When the source inspector would have to travel long distances each day to the shop

When the shop is fully loaded with items to be fabricated and schedule is tight

QUESTION 42
Which of the following is a typical topic for the pre-inspection meeting prior to the start of fabrication?

Employee annual leave planning

Quality requirements such as ITP, NCRs, and inspection frequency

Future plant expansion strategy

End-user operating philosophy only

QUESTION 43
According to IEEE 841, unless otherwise specified, all electrical performance tests shall be conducted in accordance with:

NEMA MG-1.

IEEE Std 112.

IEEE Std 117.

IEEE Std 522.
